Full Hard Galvalume Steel Coil For Road Signs

    Thickness: 0.13mm - 1.0mm



    Width: 750mm - 1250mm, all available



    Coating Weight: AZ50 to AZ185

The Full Hard Galvalume Coil has a wide range of applications. Its yield strength is as much as 550MPa, with surface hardness varies from  HV 150 to 170. As a professional manufacturer of full hard galvalume steel in China, Shanghai Metal can provide coated steel sheets that are widely used in the production lines of white goods and black appliances, such as building materials, decorative materials, refrigerators, washing machines, air conditioner, digital video, computers, audio equipment, etc.


Specifications of Full Hard Galvalume Steel Coil:

1) Capacity: over 15,000 ton per month for galvalume steel
2) Standard: AISI, ASTM, BS, DIN, GB, JIS
3) Thickness: 0.13mm - 1.0mm, all available
4) Width: 750mm - 1250mm, all available
5) Length: according to the customer's request
6) Coil ID: 508/610mm
7) Coil weight: according to the customer's request
8) Coating Weight: AZ50 to AZ150
9) Spangle: regular spangle, small spangle, big spangle

10) Steel Type & Grade:


11) Surface Treatment:


Features of Full Hard Galvalume Steel Coil:

1) Composed of 55% aluminum, 43.5% zinc and 1.5% silicon

2) Formable, weldable and paintable

3) Superior corrosion resistance in the most atmospheric conditions. This is achieved through the combination of the sacrificial protection of the zinc and the barrier protection of the aluminum

4) Coating out-performs galvanized coating from 2-6 times than hot dip galvanized steel

Packaging of Full Hard Galvalume Steel Coil

Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) Shanghai Metal Standard

2) Customization

Applications of Full Hard Galvalume Steel Coil:

1) Construction: roofing, cladding, structural sections, composite panels, etc.

2) Electric appliance: washing machine, refrigerators, toaster, microwave, etc.

3) Others: air duct, lighting, computer casing, etc.



There are a wide range of applications for full hard galvalume steel coil, others include guardrails, ventilation ducts, gutters and down spouts, pre-paint and post paint applications, gutters and ceiling suspension bars, shutter door rails. Auto parts, electrical appliances, refrigerator appliances, signs, automotive parts, vending machines, washing machines, showcases and other structural use, roofing, commercial use, etc.
