Specifications of Welded Stainless Steel Pipe/Tube for Heat Exchanger Tube:

1) Standard:

ASTM A213 /ASME SA 213, ASTM A269/ASME SA269,

A312,  A688, A803, A789, A790, A376,

EN 10216-5, EN 10297,

DIN 17456, DIN 17458,

GOST 9941, GOST 9940,

JIS G3446, JIS G3447, JISG3448, JIS G3459, JIS G3463, JIS G 3468

2) Material:

TP304/304L, TP316/316L, TP321309S, 310S, 2205, 2507, 904L, TP405, TP409, TP410S, TP430, TP439,

08X18H10, 03X18H11, 08X18H10T, 12X18H10T, 08X17H14M2, 03X17H14M2, 10X17H13M2T, 20X23H18,

SUS304TP, SUS304LTP, SUS304HTP, SUS316TP, SUS316LTP, SUS316HTP,

SUS321TP, SUS321HTP, SUS347TP, SUS347HTP, SUS310STP SUS317TP, SUS890LTP,

EN1.4301, 1.4306, 1.4948, 1.4401, 1.4404, 1.4571,

1.4541, 1.4833, 1.4878, 1.4550, 1.4462, 1.4438, 1.4845.

3) Size Range for tubing: OD:1/4" (6.25mm) to 8" (203mm), WT 0.02" (0.5mm) to 0.5"(12mm)

4) Length:30 m(Max) or as your requirement
5) Process: Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube
6) Finish: Annealed & pickled, bright annealing, polished

Ends: Beveled or plain end, square cut, burr free, Plastic Cap at both ends

Features of Welded Stainless Steel Pipe/Tubes for Heat Exchanger Tube:

1) A large stock of pipes ready for call-off
2) Pipes manufactured to specified dimensions on request
3) Pipes can be produced in high quality alloys
4) Pipes can be supplied in a variety of finishes
5) Pipes can be cut to size on our premises ready for immediate supply
6) Worldwide shipping
7) Pipes produced to ISO 9001:2000 quality specification

Manufacturing Process of Welded Stainless Steel Pipes/Tubes for Heat Exchanger Tube

The process commences with the formation of welded mother tube on the tube mill from imported and tested prime quality stainless steel strips. The latest TIG multi electrode welding technique is employed for superior weld quality and 100% Fusion, with argon purging, No filler metal added.

Packaging of Stainless Steel Tubes/Pipes for Heat Exchanger Tube

Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) Shanghai Metal Standard

2) Customization

We wrap all stainless steel products with anti-rust paper and steel rings to prevent damage. Our storage racks are made of wood and other kinds of metals are placed in other places, far from the stainless steel. Any unwanted chemical reaction can be prevented.

Applications of Welded Stainless Steel Pipes/Tubes for Heat Exchanger Tube:

1) Petroleum, chemical industry, super heater of boiler, heat exchanger

2) High temperature resistant transmission fluid pipe in power station

3) Ship with pressure pipe

4) The exhaust purification device

5) Construction and ornament
